Race-Proven In The Mud
The Ira Ryan Cyclocross CX
Born from grueling wet weekends at Portland Cross Crusade. Razor-sharp steering for hairpins, high bottom bracket clearance for remounts, and a flattened oval top tube designed to rest painlessly on your shoulder during steep run-ups.
Race Performance
Pure Acceleration & Mud Clearance
When a course turns into a peanut-butter bog, clearance at the chainstays and fork crown keeps your wheels spinning while competitors clog up. Our S-bend chainstays provide ample room for 700x38–42c tires even with packed mud.
Tuned True Temper and Columbus tubing ensures explosive snap out of corners without sacrificing the vertical compliance needed to stay seated over frozen rutted grass.
- Ergonomic Shouldering Top Tube: Gently ovalized profile for comfort over the shoulder.
- Internal or Top-Routed Cables: Keeps shifting clean and out of the way of carrying hands.
- Disc or Traditional Canti: Flat mount 140/160mm disc or classic Paul cantilever mounts.
CX Specifications
Build Sheet
| Component | CX Race Specification | All-Road / Gravel Option |
|---|---|---|
| Tubing | True Temper OX Platinum / Columbus Spirit CX | Heat Treated Chromoly |
| Tire Clearance | 700C x 38mm (UCI 33c legal with 10mm mud gap) | 700C x 45mm / 650B x 50mm |
| Bottom Bracket Drop | 60mm (High clearance for pedaling through off-cambers) | 68mm (Lower center of gravity) |
| Braking | Flat Mount 160/140mm Disc | Short-Pull Cantilever |
